美国-HONEYWELL-传感器

当前位置：网站首页 >代理产品 > 美国-HONEYWELL-传感器

产品名称：美国HONEYWELL扭矩传感器
产品类别：美国-HONEYWELL-传感器
型号：
资料下载：无资料下载
评分产品纠错

产品说明

美国HONEYWELL扭矩传感器

TMS9250 CUSTOM FLANGE	Model TMS9250 Custom Flange Digital Telemtry Torque Measurement System, Accuracy 0.05% or better
TMS9000 INTEGRAL COUPLING	Model 92005 Integral Coupling / Torque Measurement System, 250 lb-ft & up, Accuracy 0.05% or better
TMS9000 SHAFT	Model 92120 Series Shaft Style Digital Telemetry Torque Measurement System, 50 oz-in to 500,000 lb-in, Accuracy 0.05% or better, ( export only )
TMS9000 SAE	TMS9000 SAE Series Flanged Digital Telemetry Torque Measurement System, 50 lb-ft to 8,000 lb-ft, configured to mate to SAE drive shaft flanges, Accuracy 0.05% or better.
TMS9000 DIN	TMS9000 DIN Series Flanged Digital Telemetry Torque Measurement System, 50 lb-ft to 8,000 lb-ft, DIN 65 - DIN 225 sizes, Accuracy 0.05% or better.
1754	Model 1754 Square Drive Non-contact Amplified Output Rotary Torque Sensor, 500Nm to 2000Nm, Non-linearity < ±0.15 % rated output
1700	Model 1700 Series ( 1700 - 1706 ) Non-Contact/Amplified Output Torque Transducer, 0.02 Nm to 1,500 Nm, 0.1 % Accuracy
6129	Model 6129 Slip Ring Assembly, 2" bore, 4 channel, 8 channel, and 12 channel available
6118	Model 6118 Slip Ring Assembly, 0.5" bore, 4 channel, 8 channel, and 12 channel available
6116	Model 6116 Slip Ring Assembly, 1.5" bore, 4 channel, 8 channel, and 12 channel available
6105	Model 6105 Slip Ring Assembly, for 1" bore, 4 channel, 8 channel, and 12 channel available
1308	Model 1308 Rotary Slip Ring Propellar Torque Sensor, 1,000 lb-in to 20,000 lb-in, ±0.25 % non-linearity rated output
1239	Model 1239 Rotary Slip Ring Propellar Torque Sensor, 5,000 lb-in to 20,000 lb-in, ±0.25 % non-linearity rated output
1242	Model 1242 Rotary Slip Ring Propellar Torque Sensor, 30,000 lb-in to 60,000 lb-in, ±0.25 % non-linearity rated output
1115	Model 1115 Rotary Slip Ring Torque Sensor, 50 lb-in to 10,000 lb-in, Non-linearity & hysteresis of 0.1%, Spline Drive/Flange Mount
1369	Model 1369 Steering Effort Torque Sensor, 50 lb-ft to 200 lb-ft, < 0.50 % Non-linearity and Hysteresis, SAE 10 Spline Column Attachment
1388-102	Model 1388-102 Sprocket/Pulley Torque Sensor, 500 lb-in, 1,000 lb-in, 0.1 % Non-linearity and Hysteresis, slip ring style
1246	Model 1246 Wheel Torque Sensor, 20K lb-in to 200K lb-in, 0.25 % Non-linearity and Hysteresis
1254	Model 1254 Socket Wrench Torque Sensor with optional Encoder (E), 50 lb-in to 200 lb-in; 50 lb-ft to 1,000 lb-ft, Hex drive (50 & 100 in-lb sizes) and Square Drive Configurations 200 lb-in & up, 0.15 % Non-linearity and Hysteresis, Incremental Encoder (optional), Adaptable for Portable Usage
1248	Model 1248 Flange Drive Torque Sensor, 20,000 lb-in, 0.15 % Non-linearity and Hysteresis
1228	Model 1228 Flange Drive Torque Sensor, 2000 lb-in to 10,000 lb-in, 0.15 % Non-linearity and Hysteresis
1100	Model 1100 Series ( 1104-1107 ) Rotary Slip Ring Torque Sensor, ranges from 100 lb-in to 100,000 lb-in, 0.1 % Non-linearity and Hysteresis, circular keyed shaft configuration
1102	Model 1102 Low Capacity Rotary Slip Ring Torque Sensor, 50 oz-in to 1,000 oz-in, 0.1 % Non-linearity and Hysteresis, circular shaft configuration
1103	Model 1103 Low Capacity Rotary Slip Ring Torque Sensor, 10 oz-in to 20 oz-in, 0.05 % Non-linearity and Hysteresis, circular shaft configuration
1615	Model 1615 Rotary Transformer Torque Sensor, 50 lb-in to 10,000 lb-in, Non-linearity & hysteresis of 0.1%, Spline Drive/Flange Mount
1388-124	Model 1388-124 Sprocket/Pulley Torque Sensor, 500 lb-in, 1,000 lb-in, 0.1 % Non-linearity and Hysteresis, rotary transformer style
1815	Model 1815 Series Enhanced Accuracy Rotary Torque Sensor, 0.05 % Non-linearity and Hysteresis, 50 lb-in to 10,000 lb-in, Spline Drive/Flange Mount, Extended Speed Range, up to 25,000 RPM
1641	Model 1641 Rotary transformer Flange Drive Torque Sensor, 20000 lb-in to 100000 lb-in, 0.1 % Non-linearity and Hysteresis
1648	Model 1648 Rotary transformer Flange Drive Torque Sensor, 2,000 lb-in to 20,000 lb-in, 0.1 % Non-linearity and Hysteresis
1800	Model 1800 Series ( 1804 - 1807 ) Enhanced Accuracy Rotary Torque Sensor, 0.05 % Non-linearity and Hysteresis, 100 lb-in to 100,000 lb-in, Extended Speed Range, up to 27,000 RPM
1600	Model 1600 Series ( 1604 -1607 ) Rotary Transformer Torque Sensor, 50 lb-in to 100,000 lb-in, 0.1 % Non-linearity and Hysteresis, circular keyed shaft configuration
1602	Model 1602 Low Capacity Rotary Transformer Torque Sensor, 10 oz-in to 1,000 oz-in, 0.1 % Non-linearity and Hysteresis, circular shaft configuration
2320	Model 2320 Flanged Reaction Torque Sensor, 12,000 lb-in to 36,000 lb-in, 0.1 % Non-linearity and Hysteresis
2404	Model 2404 Hollow Reaction Torque Sensor, 50 lb-in to 5K lb-in, 0.1 % Non-linearity and Hysteresis
QSFK-9	Model QSFK-9 Shaft Type Reaction Torque Transducer, 100 in-lb to 24,000 in-lb, maximum non-linearity of 0.1%, stainless steel
2120	Model 2120 Series Shaft Reaction Torque Sensor, 100 lb-in to 500,000 lb-in, 0.1 % Non-linearity and Hysteresis
2120 Low	Model 2120 Low Shaft Reaction Torque Sensor, 50 oz-in to 1,000 oz-in, 0.1 % Non-linearity and Hysteresis
QWLC-8M	Model QWLC-8M Miniature Reaction Torque Transducer, 25 in-oz to 250 in-oz, 50 in-lb to 300 in-lb, maximum non-linearity of 0.1%, Compact, Stainless Steel
QWFK-8M	Model QWFK-8M Miniature Reaction Torque Transducer, 25 in-oz to 250 in-oz, 50 in-lb to 300 in-lb, maximum non-linearity of 0.1%, Compact, Stainless Steel
2105	Model 2105 Low Capacity Reaction Torque Sensor, 50 oz-in to 1,000 oz-in, maximum non-linearity of 0.1%, flange / shaft configuration
QFFH-9	Model QFFH-9 Flange Type Reaction Torque Transducer, 3,000 in-lb to 24,000 in-lb, maximum non-linearity of 0.1%, Stainless Steel
2110	Model 2110 Series Flanged Reaction Torque Sensor, 2,000 lb-in to 2,400,000 lb-in, 0.1 % Non-linearity and Hysteresis
2102	Model 2102 Small Flanged Reaction Torque Sensor, 50 lb-in to 1,000 lb-in, 0.1 % Non-linearity and Hysteresis
